Molex LED Array Holder for Citizen CL-L340
The Molex 180190-0000 and 180190-0001 LED Array Holders are designed for use with the Citizen CL-L340 LEDs and have gold (Au) plating. The 180190-0000 comes without a lens cover, and the 180190-0001 comes with a lens cover.
View all Molex LED Array Holders
View Molex LED Array Holder Heat Sink
Features
- ELV and ROHS compliant
- Applicable wire gauge - 18 or 20AWG
- Solid wire is recommended
- If stranded wire is used, pre-tinned is recommended
- 1cm strip length is recommended
- Mount holder using M3 or 4-40 screws (2), 0.8N•m max torque
- UL recognized to UL496
- c-UL recognized to CSA-C22.2 No. 43 (2008)
- Rated 600V
- UL file number: E345583, UL-OLFB2
Materials
- Caps: natural color PA66 nylon
25% GF UL94V-0
- Housing: natural color PA66 nylon
25% GF UL94V-0
- Cover lens: clear polycarbonate UL94HB
- Wire trap terminals: copper alloy
|
